Details
The 7100-1 ladders are one section straight ladders made with non-conductive fiberglass rails. Easy to transport and maneuver, these ladders bear a duty rating of 375 pounds making them durable and long lasting. The slip-resistant, TRACTION-TRED rungs are round, and the durable rail shields and shoe brackets help to protect the rails from damage. The plate and rung assemblies are riveted at four points to the side rails.
Specifications
Size: 20'
Reach Height: 23'
Load Capacity: 375 lbs.
Type: Type IAA Duty Rating
Material: Fiberglass
Rung Type: Round
Foot Material: Slip-resistant pad
Number of Sections: 1
Certifications: ANSI A14.5 (2007); OSHA
Approx. Cu. Ft. Per Unit: 13.9
Approx. Shipping Wt. Lbs.: 58
Dimensions
Rails Dimension: 4"
Flange Dimension: 1-3/4"
Rung Dimension: 1-1/4"
Fly Width: 16-13/16"
Base Width: 18-1/16" outside shoes
Additional 7100-1 Series Models
| Model No. | Size | Reach Height | Approx. Cu. Ft. Per Unit | Approx. Shipping Wt. Lbs. |
| 7108-1 | 8' | 11' | 4.5 | 20 |
| 7110-1 | 10' | 13' | 5.5 | 24 |
| 7112-1 | 12' | 15' | 6.5 | 28 |
| 7114-1 | 14' | 17' | 7.6 | 32 |
| 7116-1 | 16' | 18' | 8.6 | 40 |
| 7118-1 | 18' | 21' | 12.5 | 52 |
| 7120-1 | 20' | 23' | 13.9 | 58 |
